T Tocas 60A Type Iii Surface-Mount Circuit Breakers For Boat Marine Rv Yacht Battery Truck Solar, 12V – 48V Dc,Waterproof, 60 Amps Dc Breaker

Sale!
T Tocas 60A Type Iii Surface-Mount Circuit Breakers For Boat Marine Rv Yacht Battery Truck Solar, 12V - 48V Dc,Waterproof, 60 Amps Dc Breaker

T Tocas 60A Type Iii Surface-Mount Circuit Breakers For Boat Marine Rv Yacht Battery Truck Solar, 12V – 48V Dc,Waterproof, 60 Amps Dc Breaker

Original price was: $26.47.Current price is: $15.05.

14 in stock

SKU: WBCARB07PBGMMNZ Category:

Description

Note:The color of the reset lever and push to reset button will be red or yellow(It will be in random)

Typically used in auxiliary and accessory circuits in truck, bus’, RVs and marine applications.
Others include battery charger and DC audio system.

Voltage:up to 48Vdc
Rated Current:Consult Factory
MountingWide:Surface Mount
Reset Type:T3, Manual
Operating Temperature:-32ºC (-25ºF) to 82ºC (180ºF)
Interrupt Capacity:

2,500A @ 14Vdc (25-200A)
1,500A @ 48Vdc (25-200A)
1,500A @ 14Vdc (225A-300A)

Regulatory Sepcification:SAE J1625; SAE J1171; UL 1500; ABYC E-11; CE; IP67
Termination:1/4 Stainless Steel Studs
Body:UL-rated 94V0 thermoset plastic
Storage Temperature:-34ºC (-30ºF) to 149ºC (300ºF)

Packing list:
1 * 60 Amp Circuit Breaker with Manual Reset
